ND16+592843+Primary Indicating Lamp

Get a Price/Quote

ND16+592843+Primary Indicating Lamp Specification

Lighting Type
Indicator Light

Connector Type
Push-fit, Screw Terminal

Color Temperature
~5000 K (white)

OE Number
ND16+592843

Input Voltage
24 Volts

Life Span
30,000 hours

Features
Vibration resistant, Easy installation, Low power consumption

Lens Material
Polycarbonate

Lumen flux
40-60 lm

Water Resistance
IP54

Accessories
Mounting Clips, Wiring Kit (options available)

Usage
Vehicle dashboard indication, control panels

Color
Multiple (as per selection)

Operating Temperature
-20C to +60C

Mounting Type
Panel Mounted

Beam
Diffused

Product Type
Primary Indicating Lamp

Bulb Type
LED

Voltage
24V DC

Car Make
Universal, compatible with multiple commercial vehicles

Body Material
Polycarbonate (PC)

Power
1W

Lighting Color
Red, Green, Amber, Blue, White (available options)

Rated Current
<20 mA

Weight
Approx. 18 grams

Diameter
16 mm (panel cut-out)

Response Time
<10 ms

Insulation Resistance
>100 M (at 500V DC)

Dielectric Strength
2kV AC for 1 min

Housing Color
Black

Storage Temperature
-30C to +80C

Protection Class
Class II

About ND16+592843+Primary Indicating Lamp

Introducing the spectacular ND16+592843 Primary Indicating Lamp-your special solution for dominant dashboard and control panel indication. For a limited time, gain access to this breathtaking LED lamp, designed for universal commercial vehicle compatibility. With a rugged 16 mm panel cut-out, brilliant color options, and a rapid <10 ms response, it offers unrivaled visibility and reliability. Crafted from impact-resistant polycarbonate, boasting IP54 water resistance, 2kV dielectric strength, and an impressive 30,000-hour lifespan, this indicator sets a new standard in robust, energy-efficient performance for any demanding application.

ND16+592843: Unmatched Features and Versatile Applications

The ND16+592843 Primary Indicating Lamp stands out with its vibration-resistant build, IP54 water resistance, and multiple color options, ensuring it meets every signaling need. Its robust housing and panel mounting design suit a range of surfaces, including vehicle dashboards, industrial control panels, and machinery interfaces. With polycarbonate durability and quick installation, this indicating lamp excels in commercial vehicles and versatile equipment, offering dependable, long-lasting performance in the most demanding environments.

Payment, Packaging, and Domestic Market Reach

With reasonable expenditure and transparent outlay, purchasing the ND16+592843 lamp is hassle-free. Flexible payment terms accommodate businesses of all scales, while the product arrives carefully packed to prevent damage during storage or drop-off. Our main domestic market spans across India, supported by efficient supply chains and dependable after-sales service. Enjoy peace of mind knowing your investment in safety and reliability is well-protected throughout the transaction and delivery process.

FAQ's of ND16+592843+Primary Indicating Lamp:

Q: How is the ND16+592843 Primary Indicating Lamp installed?

A: This lamp is designed for quick and simple panel mounting using supplied mounting clips and optional wiring kits. Its push-fit and screw terminal connectors facilitate easy and stable installation, even in compact dashboard or control panel locations.

Q: What are the key benefits of using this indicating lamp in commercial vehicles?

A: The lamp offers breathtaking visibility, rapid response, and dominant reliability. Its robust polycarbonate housing, IP54 water resistance, and high insulation make it suitable for harsh conditions, while low power consumption and a 30,000-hour lifespan ensure maximum efficiency and minimal maintenance.

Q: Where can the ND16+592843 lamp be applied besides vehicle dashboards?

A: Other than dashboards, it is ideal for control panels, industrial equipment, automation systems, and machinery interfaces that require clear and durable LED status indication.

Q: What lighting colors are available, and how do I select the right one?

A: The lamp is available in red, green, amber, blue, and white. Selection depends on your specific signaling requirements-each color can communicate different statuses or warnings on your equipment or control panel.

Q: What is the process for ordering and receiving the product?

A: Order with your preferred specifications and color. After confirming payment through our flexible terms, the lamp is securely packaged and delivered quickly, with drop-off options tailored to your location within India.
