NM1 MCCB

Get a Price/Quote

NM1 MCCB Specification

Rated Short Circuit Breaking Current
Up to 50kA

Rated Short Circuit Making Current
Up to 50kA

Mechanical Life
10,000 Operations

Phase
Single/Three Phase

Breaking Capacity
16kA to 50kA

Product Type
Moulded Case Circuit Breaker (MCCB)

Installation Options
Fixed

Function
Overload and Short Circuit Protection

Poles Number
1P, 2P, 3P, 4P

Rated Voltage
AC 400V, 690V

Rated Current
16A to 630A

Rated Frequency
50/60 Hz

Curves
B, C, D Curves

Temperature Protection
Thermal Adjustable

Weight
Approx. 1.5 kg

Color
White/Grey

Connection Type
Screw Terminal

Trip Type
Thermal Magnetic

Operating Temperature Range
-5°C to +40°C

Adjustment Range
0.8 to 1.0 In

Auxiliary Contacts
Optional

Enclosure Protection
IP20

Electrical Life
2,000 Operations

Mounting
Panel Mounting

Release Type
Fixed/Adjustable

Ambient Temperature
-5°C to +40°C

About NM1 MCCB

Experience the triumphant arrival of the new release NM1 MCCB, a celebrated choice among venerable electrical solutions. Customizable with adjustable or fixed trip types and optional auxiliary contacts, this panel-mounted circuit breaker ensures overload and short circuit protection for single or three-phase applications. Designed for reliability with a robust IP20 enclosure, it operates efficiently in ambient temperatures from -5C to +40C. Available in white or grey, supporting rated currents from 16A to 630A and short circuit capacities up to 50kA. Buy from trusted manufacturers, suppliers, and traders across India for unparalleled safety and performance.

Versatile Protection Across General and Specific Use

The NM1 MCCB is engineered for both general and specific electrical applications, making it ideal for residential, commercial, and industrial use. Features include thermal magnetic trip, adjustable release, and multiple pole options. This customizable unit accommodates diverse electrical needs while ensuring user safety with overload and short circuit protection. Suitable for fixed or panel mounting, it's perfect for those who require dependable and adaptable circuit protection with a celebrated history of performance.

Favorable Payment Options and Swift Logistics

We provide the NM1 MCCB at the lowest price, backed by convenient payment terms including advance payment or flexible installment options. Quick dispatch and efficient drop-off ensure minimal wait times for clients both local and international. Our transparent sample policy allows inspection before purchase. We regularly export to major markets, ensuring that our offerings reach you swiftly, reliably, and with the highest standards of customer service.

FAQ's of NM1 MCCB:

Q: How does the NM1 MCCB provide overload and short circuit protection?

A: The NM1 MCCB utilizes a thermal magnetic trip mechanism and adjustable releases to effectively detect and interrupt overloads or short circuits, safeguarding electrical systems during abnormalities.

Q: What installation options are available for this MCCB?

A: The NM1 MCCB supports both panel mounting and fixed installations, offering flexibility for diverse electrical setups in residential, commercial, or industrial environments.

Q: Where can I use the NM1 MCCB?

A: This circuit breaker is suitable for general power distribution and specific applications in single or three-phase systems, including homes, offices, factories, and industrial plants.

Q: What are the auxiliary contact options for the NM1 MCCB?

A: Auxiliary contacts are optional and offer additional control or monitoring functionalities, enabling integration with external alarm systems or remote monitoring solutions.

Q: How is the NM1 MCCB shipped and what is the delivery process?

A: After order confirmation, products are quickly dispatched through efficient logistics partners, ensuring timely drop-off at your location. International orders are handled to ensure swift, secure delivery.

Q: What is the adjustment range for the current settings?

A: The adjustment range for the NM1 MCCB is from 0.8 to 1.0 times the rated current (In), allowing users to fine-tune settings based on system requirements.
