NXC-09 AC Contactors

Get a Price/Quote

NXC-09 AC Contactors Specification

Surface Finish
Matte

Mounting Type
DIN Rail or Panel Mount

Power Factor
0.7 min (AC coil)

IP Rating
IP20

Insulation Material
Polycarbonate

Connector Type
Screw Connection

Operating Temperature
-5°C to +40°C

Shape
Rectangular

Overheating Protection
Available via compatible Thermal Overload Relay

Efficiency
High Efficiency Switching

Feature
Long Life, High Reliability

Humidity %
≤ 50% at 40°C

Product Type
AC Contactor

Application
Motor Control, Power Switching

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
690 V AC

Energy Consumption
4 VA

Output Type
Switching

Color
Grey and Blue

Dimension (L*W*H)
77 x 45 x 82 mm

Weight
235 g

Phase
Three Phase

Input Voltage
220/230V AC Coil Voltage

Size
Standard

Connection Type
Screw Terminal

No Of Poles
3

Material
Flame Retardant Plastic + Copper

Electrical Life
1 Million Operations

Mechanical Life
10 Million Operations

Coil Power Consumption
AC: 4 VA

Auxiliary Contact
1 NO+1 NC

Category
Power Contactor

Altitude Limit
Up to 2000 m above sea level

Rated Current
9A

Shock Resistance
11 ms, 10g

Storage Temperature
-25°C to +55°C

RoHS Compliance
Yes

Vibration Resistance
Up to 5g (10-200 Hz)

Making/Breaking Capacity
10 x Ie (AC-3)

About NXC-09 AC Contactors

Access masterful control and protection with the magnificent NXC-09 AC Contactors, expertly engineered for value and reliability. With a robust rated current of 9A, majestic making and breaking capacity (10 x Ie, AC-3), and awe-inspiring operational longevity (mechanical life: 10 million, electrical life: 1 million operations), these contactors assure optimal performance for your applications. Enjoy the best price without compromising safety-thanks to RoHS compliance, flame retardant construction, and IP20 protection. Ideal for power switching and motor control, this contactor provides masterful efficiency across industrial environments while offering long-lasting durability and peace of mind.

Versatile Usage for Exceptional Control

The NXC-09 AC Contactor is designed for both specific and general use in motor control, power switching, and industrial automation. Easily mountable on DIN rails or panels, it delivers reliable switching for three-phase operations and offers high efficiency with minimal power consumption. Its robust rectangular form, flame retardant material, and screw terminal connections enable seamless integration, ensuring safe and effective management of electrical circuits in standard industrial setups or specialized installations.

Focused Export Markets and Swift Delivery

NXC-09 AC Contactors are actively exported to leading markets in Asia, Africa, and the Middle East. We ensure quick dispatch and secure shipping from major Indian FOB ports, guaranteeing product integrity upon arrival. Our contactors meet international standards with RoHS and other relevant certifications, providing peace of mind to global clients. Whether you are a manufacturer, supplier, or trader, our efficient logistical network supports a smooth export process and reliable supply chain experience.

FAQ's of NXC-09 AC Contactors:

Q: How can the NXC-09 AC Contactor be used in industrial applications?

A: The NXC-09 AC Contactor is specifically suitable for motor control, power switching, and automation in industrial environments. Its robust design and reliable switching capability make it ideal for general and specialized electrical circuit management.

Q: What are the main benefits of using the NXC-09 AC Contactor?

A: You benefit from long mechanical and electrical life, high efficiency switching, and secure flame-retardant construction. Its value is enhanced by ease of installation, IP20 protection, and compliance with international RoHS standards.

Q: Where can the NXC-09 AC Contactor be installed?

A: This contactor fits standard DIN rail or panel mounting, making it adaptable for integration in control panels and distribution boards across a variety of applications.

Q: What certifications and protections does the product offer?

A: The NXC-09 AC Contactor is certified with RoHS compliance, features IP20 protection, and supports overheating protection when used with compatible thermal overload relays, ensuring safety and environmental standards.

Q: How quickly can the NXC-09 AC Contactor be delivered to export markets?

A: With our quick dispatch system and secure shipping from major FOB ports in India, international clients receive their orders efficiently and reliably, supporting uninterrupted operations.

Q: What is the process for connecting and operating the contactor?

A: Connection is straightforward using screw terminals, and operation is reliable within recommended voltage, temperature, and humidity ranges for its rated phases and currents.
